F1 | DC Enclosed Switch-Disconnector | 32A | 1200Vdc
Description
Compact switch-disconnectors in plastic or aluminum enclosure. They are available in 32A to 1200Vdc, with different connection schemes of 2P and 4P. Their design is specifically made for application in the photovoltaic sector, both in photovoltaic installations and in green energy projects. They have two different types of handle; black handle with lock and yellow/red emergency handle with lock. The enclosure has an IP66 protection category.
Codes
Plastic
| Amp | Handle | Scheme | Codes |
| 32 | 4 | 2P | F1-00322P4EP |
| 32 | 4 | 4P | F1-00324P4EP |
| 32 | 4 | 4B | F1-00324B4EP |
| 32 | 4 | 4T | F1-00324T4EP |
| 32 | 4 | 4S | F1-00324S4EP |
| Amp | Handle | Scheme | Codes |
| 32 | 3 | 2P | F1-00322P3EP |
| 32 | 3 | 4P | F1-00324P3EP |
| 32 | 3 | 4B | F1-00324B3EP |
| 32 | 3 | 4T | F1-00324T3EP |
| 32 | 3 | 4S | F1-00324S3EP |
Aluminium
| Amp | Handle | Scheme | Codes |
| 32 | 4 | 2P | F1-00322P4EA |
| 32 | 4 | 4P | F1-00324P4EA |
| 32 | 4 | 4B | F1-00324B4EA |
| 32 | 4 | 4T | F1-00324T4EA |
| 32 | 4 | 4S | F1-00324S4EA |
| Amp | Handle | Scheme | Codes |
| 32 | 3 | 2P | F1-00322P3EA |
| 32 | 3 | 4P | F1-00324P3EA |
| 32 | 3 | 4B | F1-00324B3EA |
| 32 | 3 | 4T | F1-00324T3EA |
| 32 | 3 | 4S | F1-00324S3EA |
