PRODUCTS | DC Compact Switch-disconnectors | F1 | Compact Switch-Disconnector | 32A

F1 | Compact Switch-Disconnector | 32A

-->

Description

F1 DC compact switch-disconnector are available in different connection schemes of 2P and 4P for 800-1000-1200-1500Vdc. This series has 5 different mounting types: DIN rail mounting, panel mounting, door interlock, plastic enclosure and aluminum enclosure. In addition, they have five different types of handle: Direct lockable,  external lockable black, external lockable red-yellow. These modular switch-disconnectors are designed according to IEC/EN60947-3 certification and a category of use DC-PV1 and DC-PV2.

To get more information, download the catalogue.

Códigos

DIN Rail

Handle Scheme Code
1 2P F1-00322P1DB
1 4P F1-00324P1DB
1 4B F1-00324B1DB
1 4T F1-00324T1DB
1 4S F1-00324S1DB

Panel Mounting

Handle Scheme Code
4 2P F1-00322P4PM
4 4P F1-00324P4PM
4 4B F1-00324B4PM
4 4T F1-00324T4PM
4 4S F1-00324S4PM



Handle Scheme Code
3 2P F1-00322P3PM
3 4P F1-00324P3PM
3 4B F1-00324B3PM
3 4T F1-00324T3PM
3 4S F1-00324S3PM

Handle Scheme Code
7 2P F1-00322P7PM
7 4P F1-00324P7PM
7 4B F1-00324B7PM
7 4T F1-00324T7PM
7 4S F1-00324S7PM



Handle Scheme Code
6 2P F1-00322P6PM
6 4P F1-00324P6PM
6 4B F1-00324B6PM
6 4T F1-00324T6PM
6 4S F1-00324S6PM



Door Interlock

Handle Scheme Code
4 2P F1-00322P4DC
4 4P F1-00324P4DC
4 4B F1-00324B4DC
4 4T F1-00324T4DC
4 4S F1-00324S4DC

Handle Scheme Code
3 2P F1-00322P3DC
3 4P F1-00324P3DC
3 4B F1-00324B3DC
3 4T F1-00324T3DC
3 4S F1-00324S3DC

Handle Scheme Code
7 2P F1-00322P7DC
7 4P F1-00324P7DC
7 4B F1-00324B7DC
7 4T F1-00324T7DC
7 4S F1-00324S7DC

Handle Scheme Code
6 2P F1-00322P6DC
6 4P F1-00324P6DC
6 4B F1-00324B6DC
6 4T F1-00324T6DC
6 4S F1-00324S6DC
